CS1010S Lab 1 Solution

Mental State of Computation
This lab exercise will teach you how to set up the lab PC and familiarise you with the edit/compile/run cycle of C/C++ programming. You will also try writing a simple program and submitting it on Coursemology.
Understanding the State of Computation
When a program executes, state of computation is simply the contents of the computer memory at that point in time. For C/C++ programs, that would be organised as symbols and their respective values.
A symbol is just another fancy name for variables and functions. In Q1 of tutorial 1, you were required to trace through the execution of the following program:
#include <stdio.h>
int main(void) { int cur, prev1=1, prev2=1;
cur = prev1 + prev2; prev2 = prev1; prev1 = cur;
cur = prev1 + prev2; prev2 = prev1; prev1 = cur;
cur = prev1 + prev2; prev2 = prev1; prev1 = cur;
printf("cur is %d; prev1 is %d; prev2 is %d ", cur, prev1, prev2);
return 0;
}
1. What are the symbols in this program?
Solving a Problem
Let us now see how having a mental picture of the computation state can help us solve a problem.
1

Before starting to write any code, you first need to come up with the algorithm, or strategy to solve the problem on paper. One way to start is to try working out the solution with some sample inputs. The solution for n = 5,k = 3 is shown above. Can you solve n = 6,k = 4?
Seems pretty straightforward right? What about n = 6,k = 2?
When you are done, ask yourself:
1. When solving this problem on paper, what state did you maintain?
2. What was your strategy to get the answer?
3. How did the state transform with every step in your process?
To solve problems computationally, it is much simpler if you are consistent in how the state is manipulated, e.g., instead of randomly selecting candles to burn, be consistent in the number of candles to always burn.
4. Does your strategy employ a consistent state transformation?
Now express your transformations using the control structures that we learnt.
5. If your transformation is dependent on some condition, you will use .
6. If you repeat the transformation, you can use
Our Solution
We strongly recommend you try and solve this simple problem on your own before reading our answer.
Here is an example of a possible solution. Note that in programming, there can be several ways to solve a problem. This is just one example.
Our State
Here are the symbols, or variables that we maintain in our state.
• n: the number of currently unburnt candles.
• k: the number of burnt candles that can be rolled into one new candle.
• count: maintain the total number of candles we have burnt.
Did you have these variables in your strategy too?
Our Algorithm
1. Initialize count = 0
2. If n ≥ k, we can burn k candles to get a new one
(a) n = n − k; Burn k candles
(b) n = n + 1; Roll a new candle
(c) count = count + k; Count number of candles burned
3. Repeat step 2 until n < k.
4. Burn the remaining n candles.
(a) count = count + n
(b) n = n − n
5. The number of candles burned is the value in count.
Loop Invariant
An invariant is a point in the program where the state is meaningful. The values in the variables in our state should reflect the meaning as stated above.
When transforming the state, there is usually a stage where the state is “in transition”. In our algorithm, that would be steps 2(a) to 2(c), and steps 4(a) and 4(b).
At the main steps, 2 through 5, we can check that the invariant holds true, i.e., n reflects the number of unburned candles, and count records the total number of candles burned. If this is true, then we can be certain that our algorithm will always produce the correct result.
Our Code
Now it is time to write the C/C++ code. With the algorithm formerly described, it is a simple task to translate it to C/C++ code.
int candles(int n, int k) { int count = 0; // 1. Initialise count while (n >= k) { // 2. Loop if n >= k
n = n - k; // a. Burn k candles
n = n + 1; // b. Roll a new candle
count = count + k;
} // c. Increase number of candles burned
count = count + n; // 4a.
n = n - n; // 4b.
return count; // 5
}
As you can see, a lot of thinking, planning and strategizing is done before we even think about writing code. This is true especially when dealing with large and complex problems.
For small problems like this, experienced programmers often do all these mentally in their minds and can be seen just typing out the code. They are not skipping these steps but because they are so experienced, they will do it subconsciously in an instant and just write the code.
Since you are not at that level yet, you should take time to properly plan and structure your approach to solve the problem. Having a vague idea before writing code is not enough. You will end up not knowing why your code fails, or if you are lucky why it even works. And even if it works, how can you be sure it works for all inputs?
A woodsman was once asked, “What would you do if you had just five minutes to chop down a tree?”
He answered, “I would spend the first three minutes sharpening my axe.” ”
Few minutes of sharpening your axe will save your hours on the job. Few minutes spent planning and careful thought will save you hours on coding.
Hints for Problem Set 1
Task 3: Time Elapsed
How would you solve the following math equation?
=
Task 3 could be solved without using any control statements. Just like with fractions, there is a common denominator that we can covert to and do elementary addition.
Testing
You might have submitted code on Coursemology that passed all the public test cases, but fails one or more private tests. That is because your code is supposed to work for all valid inputs. So there is one particular input that your code gives the wrong result.
Since there are 24 possible values for hour, 60 possible values for minutes and 60 for seconds, there is a total of 242× 602× 602 = 7,464,960,000 possible inputs.

Even though some combinations are invalid (since the first time is no later than the second), there are still easily over a trillion combinations. It is definitely not possible to run your program through a few trillion inputs.
Equivalence Class Testing
We can make use of this technique called Equivalence Class Testing to reduce the size of the test data. In summary, it is identifying and partitioning the different combination of test inputs into different classes, and then just testing one input from each class. You can more in detail on Wikipedia or search on the Internet.
For this task, we can reduce the test space by just examining the relation between the inputs h0 and h1, m0 and m1, and s0 and s1.

Since there are only 3 different relation classes for each parameter hour, min and sec, there are now only 3 × 3 × 3 = 27 combinations. Some combination are invalid inputs so the actual number of test combination is 14.
1. Can you list down all possible classes of test inputs for this task?
2. Use these cases to test your program.
Task 4: IP Address
For this problem set, there is no need to use control statements to solve the problem, though you are free to try.
Examine the question closely. Note that the input will be an integer of at most 8 digits (without the leading 0). The formula is fixed and operates on each digit. So what remains is determine what is the value of each digit.
Using an example, 1010,
2. how about the second digit from the right? The tens place.
3. how about the third (hundreds)? the fourth (thousands)?
As with every task in this problem set, your solution can simply be a single formula.
